產品特色
- 100 MHz bandwidths.
- Sample rates up to 2 GS/s.
- Long Memory – up to 100 Mpts/Ch (200 Mpts interleaved).
- 10.1" bright capacitive color TFT-LCD touch screen (1024 x 600).
- I2C, SPI, UART, CAN, LIN Serial Bus Trigger and Decode options come as standard.
- Optional MSO – 16 Digital Channels. This adds mixed signal debugging to Oscilloscopes.
- 50 MHz function/arbitrary waveform generator with 6 built in waveforms as standard.
- Power Analysis application included as standard.
- Bode plot as standard from 10 Hz to 50 MHz available using the 50 MHz function/arbitrary waveform generator, or 10 Hz to 500 MHz using the optional T3AFG500 arbitrary function generator.
- Advanced Trigger – Edge, Slope, Pulse Width, Window, Runt, Interval, Time Out (Dropout), Pattern and Video.
- Waveform Sequence Recorder – record and playback up to 90,000 waveforms. Allows users to replay the changes which have occurred in their waveform history.
- Connectivity – USB for mass storage, printing and PC control, plus LAN. These tools enable fast export of data and screen shots for external analysis and reporting purposes.
